一、產品簡介 Product Brief
WZP系列工業用多點防爆熱電阻是一種溫度傳感器。在工業自控系統中應用極廣，通過溫度傳感器，可將控制對象的溫度參數變成電信號傳遞給顯示、記錄和調節儀表，對系統實行檢測、調節和控制。
WZP series flameproof heat resistance Is a kind of temperature sensor. In the industrial automatic control system in the application of a very wide, Through the temperature sensor, Can put the control object The temperature parameter Into electrical signals to the Display, record and control instrument, The system implements Inspection, adjustment and control.
在化工廠生產現場常伴有各種易燃、易爆等化學氣體、蒸汽、如果使用普通的熱電阻非常不安全，極易引起環境氣體爆炸。因此，在這些場合必須使用多點防爆熱電阻作溫度傳感器。本公司生產的隔爆熱電阻產品適用dIIBT4~dIICT6溫度組別區間內具有爆炸性氣體危險的場所內。
In the chemical plant Production site Often accompanied by a variety of Flammable, explosive, etc. Chemical gas, steam, If using the ordinary Thermal resistance is very unsafe, Extremely easy to cause environment gas explosion. Therefore, On these occasions You must use a flame-proof thermal resistance temperature sensor。The company's production Flameproof heat resistance products Application of dIIBT4~dIICT6 Temperature group interval With explosive gases in dangerous places.
本公司生產的多點防爆熱電阻采用引進元件作感溫元件，其技術性能符合ZBY301-85工業熱電阻技術條件和分度表。同時符合爆炸性環境用防爆電氣設備通用要求GB3836.1~2010、GB3836.2-2010標準。
The company production of explosion heat resistance isolation Introduce the element as a temperature sensing element, Its technical performance Meet ZBY301-85 Industrial thermal resistance The technical conditions and indexing table. At the same time meet for explosive environment Explosion proof electrical equipment General requirements GB3836.1~2010、GB3836.2-2010 Standard.
