一、產品簡介   Product Brief

        一體化帶顯示溫度變送器熱電偶是DDZ-S系列儀表中的現場安裝式溫度變送器單元。它集熱電偶同變送器為一體，直接測量各種工業過程中0~1600℃范圍內的液體、蒸汽和氣體介質的溫度，將溫度轉換成與熱電偶電信號成正比的4～20mA統一輸出信號，送顯示、記錄調節儀表或計算機。作為新一代的溫度變送器，它可廣泛應用于冶金、石油、化工、電力、輕工、紡織、食品、國防以及科研等各部門。

        SBWR series with a thermocouple temperature transmitter DDZ-S series instrument in Field mounted temperature transmitter unit. It sets the thermocouple with the transmitter as a whole, Direct measurement of various industrial processes 0~1600℃ Within the scope of Liquid, steam and gas medium temperature, The temperature will be converted to With the thermocouple signal Proportional 4 ~ 20mA unified output signal, Sent to the display, record control instrument Or computer. As a new generation of temperature transmitter, It can be widely used in the Metallurgy, petroleum, chemical, electric power, light industry, textile, food, Defense And scientific research departments.

       一體化帶顯示溫度變送器熱電偶件是小型化的，可安裝于熱電偶的接線盒內，成為一體化溫度變送器。作為一體化溫度變送器在工業現場直接輸出4～20mA信號，這樣既省去昂貴的補償導線，又提高了信號長距離傳送過程中的抗*力。

        SBWR series with a thermocouple temperature transmitter Is miniaturization, Can be installed in thermocouple The junction box, An integrated temperature transmitter. As the integrated temperature transmitter In the field of industrial output 4 ~ 20mA signal directly, This will not only save the expensive compensation wire, But also improves the signal long distance transmission process of anti-interference ability.

       熱電偶部件精度高、功耗低、使用環境溫度范圍寬，工作穩定可靠。且由于采用硅橡膠密封結構，變送器耐震、耐濕，適宜于惡劣現場環境中使用。具有線性化校正功能，熱電偶溫度變送器具有冷端溫度自動補償功能。

        SBWR series with a thermocouple temperature transmitter Components of high precision, low power consumption, The use of wide temperature range, The work is stable and reliable. Due to adopting silicon rubber sealing structure, Transmitter Seismic resistance, wet, Suitable for harsh field environment using. With a linear correction function, Thermocouple temperature transmitter With the cold end temperature automatic compensation function.

       SBWR系列帶溫度變送器熱電偶應用面廣，既可與熱電偶形成一體化現場安裝結構，也可作為功能模塊安裝在檢測設備中。

        SBWR series with a thermocouple temperature transmitter Wide application, With both thermocouple The formation of integration site installation structure, Can also be used as a functional module Installed in the detecting equipment.

        SBWR系列帶變送器一體化熱電偶帶現場顯示型，可以直接現場高精度顯示實時的溫度，直觀的觀察被測介質的溫度變化。同時輸出標準的4~20mA電流信號至控制室的顯示儀表或DCS系統中顯示溫度。

        SBWR series belt transmitter integrated temperature transmitter With on-site display type, Can be directly high precision display real-time temperature, Direct observation of measured medium The change of temperature. At the same time, the output standard 4~20mA The current signal to the control room. Display instrument and DCS system Temperature display.
